The FocusScan RX II is an advanced portable PAUT acquisition system encompassing Full Matrix Capture (FMC) with full-featured Total Focusing Method (TFM).

Key user-friendly features of the FocusScan RX II include two 64 element IPEX connectors, eight Lemo 00 connectors for ToFD and Pulse echo, two-axis motor drive control, positional encoding, 12” wide-aspect touchscreen, hot swappable batteries. The full TDScan software suite and ESBeamTool® are also included providing powerful detection and analysis capabilities.

For over twenty years our designers have incorporated the very latest innovations into the established Focus-Scan product line, offering a trusted acquisition solution that is relied upon in a progressive NDT industry worldwide.



Request A Quote


Send us a request to quote by selecting the options required. A member of our team will get back to you as soon as possible with more information.

The FocusScan RX II is an advanced portable PAUT acquisition system encompassing Full Matrix Capture (FMC) with full-featured Total Focusing Method (TFM).

Video(s)


Take a tour of the FocusScan RX II

Features


  • Powerful Analysis and Reporting Functions
  • On-Board 2-axis Motor Control Drive Unit
  • Import Setups from ESBeamTool®
  • User Replaceable Batteries (hot swappable)
  • Up to 64/128PR Phased Array
  • Two 64 element IPEX Phased Array Connectors
  • 2D Matrix and Dual Linear Array support
  • 8 Independent Conventional Ultrasonic Channels
  • 2 Axis Encoding, video tracking
  • Simultaneous PA,ToFD and/or PE acquisition
  • FMC/TFM
  • Multi-channel/group data acquisition
  • 128GB SSD Storage

Applications


  • General Flaw Detection
  • Pressure Vessels
  • Pipeline Girth Welds
  • Structural Welds
  • Forgings & Castings
  • Turbine Disks & Blades
  • Corrosion Surveys
  • Composites
  • Aircraft Components
  • Hydrogen Damage Surveys
  • HTHA Surveys
  • HDPE Inspection

Techniques


  • Phased Array
  • FMC/TFM
  • TOFD
  • Pulse Echo
  • Corrosion Mapping
  • Weld Zone Discrimination

Software


  • Phased Array/TFM
    • FMC – Full Matrix Capture
    • HMC – Half Matrix Capture
    • Custom
    • Virtual Source – Linear
    • Virtual Source – Swept
    • PWI – Plane Wave Imaging
    • PCI – Phase Coherence Imaging
  • TOFD
  • Pulse Echo
  • AWS
  • Strip-Scan
  • Long Range (Creeping Head Inspection Method corrosion detection)
  • TD Super-View
  • ESBeamTool® included
